5
Extra Wide Table
Use the extra wide table when the Embroidery hoop
RE20b, SQ20b or RE28b is attached to the machine.
Extract the 4 legs located the underside of the table.
Place the extra wide table on the machine.
NOTE:
Adjust the height of the extra wide table to the height of
the machine table by turning the adjusting screws of 4
legs. Otherwise the carriage may hit the extra wide table
when attached. Use a phillips screwdriver* to turn the
adjusting screw.
q
Adjusting screw
* Phillips screwdriver is not included with the machine.
q
Anti-slipping sticker (for Embroidery hoop RE28b)
Embroidery hoop RE28b unit includes the anti-slipping
sticker.
Peel and paste the sticker on the Embroidery RE28 as
shown to prevent slipping of the ne fabrics.
