User Manual – IDS ET3203L/ET4303L/ET5053L
UM600265 Rev. C, page 15 of 33
On first boot up, the Language, Time and Time Zone must be selected
When enabled, the monitor will automatically switch if a new video port is
connected.
Default: Enabled
Adjust the brightness of the display.
Default: 72(4303L default 67))
The light sensor can be toggled on or off. When the light sensor is enabled, the
brightness cannot be changed manually.
Table for light sensor is in Section 10: Appendix A
Adjust the contrast of the display.
Default: 50
The user can choose between Standard, 5%, 10% or 15% black level offset.
The saturation level of the colors change according to the chosen black level offset.
Adjusts sharpness of the displayed images.
Default: no sharpness adjustment
Sharpness function is disabled when the input source ratio is the same as the
panels native ratio
Adjusts aspect ratio of the display.
Default: Fill Screen
Fill Screen – scales the X- and Y-dimensions of the input video (up or down as
needed) to the display’s native resolution.
Fill Aspect Ratio – Assuming a landscape orientation and an input video with
aspect ratio smaller than 16:9, scales the Y-dimension of the input video (up or
down as needed) to the display’s Y-resolution, and scales the X-dimension to
maintain the aspect ratio (and fills the rest of the display with equal black bars on
the left and right).
Direct Output – 1:1, Depends on whether the scalar can support it
Adjusts color temperature. Color temperature options shall be 9300K, 7500K,
6500K, 5500K, 3200K and User Defined.
Default: User Defined
Adjusts the display’s color based on ambient color Temperature reading.
If the User Preset option is selected, the user can change the color temperature by
changing individual R, G, and B gains on a scale from 0 to 100.
Preset color modes that change the color parameters to enhance color definitions.
Available modes are: Standard, Movie, Gaming, Photo, Line mode, Color Enhance
