Product Manual, Issue 6 CMS200
www.nexo.comPage 28
Follow the routine below for Heater:
Action Button Display Test Check
Press
Heater
Press
Select heater
Press
Heater relay engaged Evaporator heater is on
Press
Heater relay
disengaged
Evaporator heater is o
Press
Press Defrost to return to the relay test menu.
Follow the routine below for All outputs:
Action Button Display Test Check
Press
All outputs
Press
Select all outputs
Press
All outputs engaged All outputs are on
Press
All outputs disengaged All outputs are o
Press
Press Defrost to return to the relay test menu.
Note
All outputs should only be engaged by experienced service personnel and repeated
switching should be avoided due to inrush currents.
