Product Manual, Issue 6 CMS200
www.nexo.comPage 12
1.3 Relay ratings
Relay Maximum IEC rating @ 100 – 240VAC Maximum UL ratings @ 120V
Compressor 10(10)A, p.f. 0.6 10FLA, 60LRA
Lights 4(4)A, p.f. 0.6 250W Ballast
Evaporator fan 6(6)A, p.f. 0.6 6FLA, 36LRA
Auxiliary 6(6)A, p.f. 0.6 6FLA, 36LRA
Note
The auxiliary relay is normally used to switch a defrost heater, or a solenoid valve, for hot
gas defrosts.
Note
This controller is designed for integration into 3rd party equipment only and should
be installed according to these instructions and all relevant local electrical and safety
standards.
1.4 Temperature input ranges
Sensor Input range (ºC) Input range (ºF)
Appliance sensor -15ºC to 50.0ºC +/- 0.5ºC 5ºF to 122ºF +/- 1ºF
Condenser sensor 50ºC to 125ºC +/- 5.0ºC 122ºF to 257ºF +/- 10ºF
Evaporator sensor -15ºC to 50ºC +/- 0.5ºC 5ºF to 122ºF +/- 1ºF
Note
The NTC thermistor from Elstat is rated at -35ºC to 125ºC (-31ºF to 257ºF).
