1 Parameterizing with GW-GNET+
gas-net F1
Page 1-4
8. Connect the DSS data interface at the device to a COM interface of the
computer using a parameterization cable.
9. Turn the calibration switch at the device to “open”.
10. Mark the parameter data record and select the Data – Export menu item
from the main or context menu of GAS-WORKS.
11. The communication program starts.
The window appearing on your screen shows the information Data transfer
into gas-net device.
As soon as the transmission has been completed, the device will be re-
started. The message Data transfer into gas-net device vanishes from
the communication window, and the type plate of the connected gas-net
device is indicated instead, stating the most important device data.
Close the communication program now.
1.2 Importing and Editing a Parameterization: Brief
Description
You may read out the current parameterization of a gas-net device via the data
interface and edit it afterwards.
The reading in is accomplished as follows:
1. Connect the PC and the flow computer by connecting the COM interface of
the computer to the DSS interface at the gas-net device using a
parameterization cable.
2. Start GAS-WORKS on your computer if you haven’t done so before.
Activate the communication program by clicking the Import – Data
interface tool in the GW-BASE toolbar.
After having successfully started the communication program, you are
connected to the device as regards data technology. The window appearing on
your screen contains some important basic device information.
3. Change to the Content tab.
4. Mark the Parameterization data record and click the lantern icon.
A Save as dialog box appears asking for the file name under which the data
record shall be saved in GAS-WORKS.
After you have entered the name and confirmed your entry by clicking OK,
the reading in of the data starts.
