Step ➋ Adjust the guide tabs to their widest position by
pushing one or both towards the sides of the
printer.
Step ➌ Insert the end of the roll into the feed slot
between the guide tabs until resistance is felt
(approximately 3").
Figure 2-4
Open Paper Guides
Figure 2-5
Feed Slot
Operation
12 980090-001 Rev.B
