Video door entry system cable riser wiring. The
video door entry units (interphones) can be connec-
ted to the cable riser in the following ways:
• in-out connection, without the aid of floor distri-
butors;
• connection with passive distributor type 692D;
• connection with active distributor type 692D/2;
• hybrid connection using the above 3 methods.
In a video installation, device termination must be
carried out using the jumpers (ABC) in the device it-
self. See the notes below for terminating devices at
the cable riser in accordance with the wiring type.
LEGEND:
B0 - Wide Touch series door entry monitor type 7311
B1 - 7200 series door entry monitor type 7211
B2 - 6600 series door entry monitor
type 6621, 662C, 6721
type 6611, 661C, 6711
B3 - 6800 series door entry monitor
type 6801, type 68MV + 68M1
B4 - Petrarca series door entry monitor
type 6029/C + 6209 + 6145
type 6029 + 6209 + 6145
B5 - Giotto series door entry monitor
type 6329, 6329/C
B6- Tab series door entry monitor
type7529, 7529/D
G - Additional power supply unit type 6923
N - Distributor type 692D
K - Door call button
X- Cable type 732H, 732I (Twisted Pair)
Monitor cable riser
Monitor cable riser
Monitor cable riser
*
CONNECTION OF MONITORS WITH AND WITHOUT FLOOR DISTRIBUTOR TYPE 692D AND 692D/2 (REF. si638).
