Default value = + .
When the following message is displayed in the 1st line:
Press push-buttons 1, 2 or 3 for , + , respectively.
Press to confirm the change or to cancel. When you confirm
the change, the message “Done!” will appear.
- 1.5 PREFERENTIAL CODE
Assigns to the push-button a call code to an interphone or monitor inter-
phone. Without pressing other push-buttons, it is possible to call a given
device by pressing the push-button .
The type of call code depends on the value set in parameter 1.3 NUM-
BER OF ENCODING DIGITS(3, 4 or 8 digits).
Default setting = (empty).
When the following message is displayed in the 1st line:
Key in all digits of the call code with push-buttons al . Use the
push-button to cancel the last digit entered.
Press to confirm the change or to cancel. To change the value
previously set, press the push-button before the numeric digits, and
use the digits and the push-button to change the value. When you
confirm the change, the message “Done!” will appear. If parameter 1.3
NUMBER OF ENCODING DIGITS is set as sequential, the entrance panel
checks that the value entered does not exceed 204; if it does, the message
“Over limit” appears.
- 1.6 PREFERENTIAL CODE
Assigns to the push-button a call code to an interphone or monitor inter-
phone. Without pressing other push-buttons, it is possible to call a given
device by pressing the push-button .
The type of call code depends on the value set in parameter 1.3 NUM-
BER OF ENCODING DIGITS(3, 4 or 8 digits).
Default setting = 000, 0000 or 00000000 (parameter disabled).
Enter the call code complete with all the digits by using the push-buttons
from to . Use the push-button to cancel the latest digit
entered.
Press the push-button to confirm the modification or the push-but-
ton to cancel. If you press before the push-button before the
numerical digits, the already recorded number gets changed; to modify
the value use the digits and the push-button . On confirmation of the
modification, the message “Done” is displayed. If the parameter 1,3 “Num-
ber of coding digits” gets entered as sequential, the panel verifies that the
entered value does not exceed 204; if it does exceed this value, this is in-
dicated by the message: “Over limit”.
The numbers from 201 to 204 correspond to porter switchboards.
- 1.7 LOCK PASSWORD
It is possible to record up to 200 different codes made up of 8 digits, to
open the lock directly from the keypad of the entrance panel (see parame-
ter 1.4 LOCK CODE). Default setting = (empty).
When the following message is displayed in the 1st line:
Use the push-buttons to select one of the 200 passwords. If
applicable, key in the password and press to select it.
Next to the desired password, press to access change mode.
Key in the code you want to record (max. 8 digits); if necessary, press
to delete the last digit entered.
Press to confirm the change or to cancel. When you confirm
the change, the message “Done!” will appear.
- 1.8 F1 CODES
It is possible to record up to 200 different max. 8-digit codes for control-
ling F1 directly from the entrance panel keypad.
Default setting = (empty).
When the following message is displayed in the 1st line:
Use the push-buttons to select one of the 200 codes. If appli-
cable, key in the code and press to select it. Next to the desired
code, press to access change mode.
Key in the code you want to record (max. 8 digits); if necessary, press
to delete the last digit entered. Press to confirm the change or
to cancel. When you confirm the change, the message “Done!” will ap-
pear!”.
- 1.9 F2 CODES
It is possible to record up to 200 different max. 8-digit codes to control F2
directly from the entrance panel keypad.
Default setting = (empty).
When the following message is displayed in the 1st line:
Use the push-buttons to select one of the 200 codes. If appli-
cable, key in the code and press to select it. Next to the desired
code, press to access change mode. Key in the code you want to re-
cord (max. 8 digits); if necessary, press to delete the last digit ente-
red. Press to confirm the change or to cancel. When you
confirm the change, the message “Done!” will appear!”.
- 2.0 DEVICE NUMBERING
If parameter 1.3 NUMBER OF ENCODING DIGITS is set to 4 or 8 digits, it
is necessary to assign a 4- or 8-digit call code to each interphone and
video interphone.
The mapping associates the physical code (from 1 to 200) of each inter-
phone and video interphone with the call code.
Default setting = (empty).
When the following message is displayed in the 1st line:
Use the push-buttons to select one of the 200 physical codes
(device ID). If applicable, key in the code and press to select it.
Next to the desired code, press to access change mode.
Key in the complete call code you want to record (up to 4 or 8 digits); if ne-
cessary, press to delete the last digit entered.
