EM TEST Compact NX5
Operating Manual V 1.06 113 / 143
12.2.3.
Extended Tests
Angle iteration stepwise
After n events the phase angle related to which the events
are released will change from A1 to A2 by steps of A until
A2 is reached. The same parameters as under Quick Start
can be selected.
Reduced Time Iteration Stepwise
After n events the duration of a single event will change from td1
to td2 by steps of td until td2 is reached.
The same parameters as under Quick Start can be selected.
Angle Inverse mode
The inverse mode can simulate a phase control circuit, switching
power (voltage) on/off at a certain phase angle. The phase angle
is selectable in the range of 0-180°. The voltage will be switched
on/off in each half-wave. Inverse is only working in U mode.
