Operation
Page 54
The operating mode can be selected from the ‘GNSS source’ option in the
‘Home’ > ‘System settings’ > ‘Advanced’ settings menu.
The antenna dimensions should be entered in metres according to the
diagram provided in Figure 22.
Figure 22 Vessel dimension measurement
Ref A
GNSS
Antenna
Ref A + Ref B = Length in metres Ref C + Ref D = Beam in metres
Ref B
Stern Bow
Ref C
Ref D
