Installation
Page 22
Figure 9 AIS transceiver dimensions
Figure 10 FLEXI-FIT bracket
150 mm
150 mm
43 mm
115 mm
115 mm
83.4 mm
60.3 mm 10 mm
71 mm
150 mm8.5 mm
3.4 mm DIA
60.3 mm
