Specifications
Page 44
6 Specifications
Parameter Value
Dimensions 149 x 118 x 47 mm (L x W x H)
Weight Transceiver only variants 320g
Transceiver with splitter variants 345g
Input voltage DC 12 - 24V (9.6 - 31.2V maximum)
Average power
consumption
Transceiver variants (B921/B922/B951/B952): 170mA /
1.6W at 12VDC
Splitter variants (B923/B924/B953/B954):
280mA / 2.1W at 12VDC
Peak current
rating
B921/B922/B951/B952 2A
B923/B924/B953/B954 2.5A
GPS Receiver
(AIS integrated)
50 channel IEC 61108-1 compliant
Electrical
Interfaces
NMEA 0183 38,400 baud
NMEA 2000 LEN=1
WiFi 2.4GHz IEEE 802.11 a/b/g/n
Output power +15dBm
Bluetooth V4.0 / Output power +11dBm
Connectors VHF antenna connector (SO-239)
VHF radio connector (SO-239) - only applicable to
splitter variants B923/B924/B953/B954
External GPS antenna connector (TNC)
NMEA 2000 connector (Micro-C)
Power/NMEA 0183/silent mode connector (12 way)
USB micro connector
