Operation
Page 39
4.4 PGN table
PGN’s are useful for understanding the detailed information that your
transceiver receives and transmits on an NMEA 2000 network. The PGN’s
listed in Table 4 are supported by the transceiver. There are no unused fields.
PGN
(Dec.)
PGN
(Hex.)
Title in NMEA database Usage
NMEA 0183
059392 0E800 ISO Acknowledgment in, out
059904 0EA00 ISO Request in, out
060416 0EC00 ISO Transport Protocol -
Data
in, out
060160 0EB00 ISO Transport Protocol -
Connection
in, out
060928 0EE00 ISO Address Claim in, out
065240 0FED8 ISO Commanded
Address
in
126208 1ED00 Group Function in, out
126464 1EE00 PGN list - Group Function in, out
126992 1F010 System time out
126993 1F011 Heartbeat out
126996 1F014 Product Information in, out
126998 1F016 Configuration Information out
127250 1F112 Vessel Heading in HDT/THS
127251 1F113 Rate if Turn in ROT
