Emax Tinyhawk User Manual

Tinyhawk
1
emax-usa.com
Product specification
Tinyhawk
Parameter
Diagonal wheelbase (without paddles)
75mm
Maximum size of the aircraft (without
antenna, cable tie)
125mm
Aircraft weight (without battery)
27.5g
Motor
TH08025 15000KV
Propeller
Avan Tinyhawk propeller 40x23x3
Main Flight Controller
F4（MATEKF411 firmware）
4 in one 3A ESC
EMAX Tiny receiver（Compatible with Frasky
remote control D8 mode）
Camera
600TVL CMOS camera
Transmitter
25mW Adjustable frequency 37CH
Battery
1 Cell 450 mAh HV lipo battery
Radio
Maximum appearance size
181×213×80(mm)
weight (without battery)
211g
Number of channels
6 Channels
Transmission frequency
2.4GHz ISM Band（2400MHz~2483.5MHz）
Output Power
22dbm
Modulation
GFSK
battery
1 cell 18650 lipo battery
Goggle
Maximum appearance size
140×153×90(mm)
weight (without battery)
398g
Resolution
480×272
battery
1 cell 18650 lipo battery

Emax Tinyhawk Specifications

General

Camera	600TVL CMOS
Wheelbase	75mm
Frame Size	75mm
Motor Size	0802
Propeller Size	40mm
FPV Camera	600TVL CMOS
Motors	0802
Video Transmitter	25mW
Propellers	Emax Avan Micro
Receiver	FrSky D8
VTX	25mW
Flight Time	4 minutes
Receiver Type	FrSky D8
Flight Controller	F4 (MATEKF411RX Firmware)
Battery	1S 450mAh LiPo
