48
EMC Connectrix B Series DS-5300B Hardware Reference Manual
Operating the DS-5300B
Figure 6 Installing the Fan Assembly in the DS-5300B
scale: 1/4" = 1"
Scale:
3/8" = 1"
3 4 5
6
1
2
2
3
1 DS-5300B 4 Status LED
2 Fan assembly unit 5 Handle
3 Captive screw 6 Non-port side
