Maintaining the DS-5300B
47
Operating the DS-5300B
2. Remove the fan assembly you are replacing from the chassis by
pulling the handle out, away from the chassis.
3. Install the new fan assembly in the chassis:
a. Orient the new fan assembly as shown in Figure 5, with the
captive screw on the right.
b. Gently push the fan assembly into the chassis until it is firmly
in.
Do not force the installation. If the fan assembly does not slide in
easily, ensure that it is correctly oriented before continuing.
c. Secure the fan assembly to the chassis by screwing in the
captive screw using the Phillips-head screwdriver.
4. Verify that the fan status LED is lit steady green to indicate
normal operation
5. Optionally, display the fan status using the fanShow command
from the CLI.
