DPSI V-Match Operating Instructions Version 1.0
Page 10 of 16
Here too, the stroke of the slave servo changes by increasing or
decreasing steps when moving the stick out of its center position.
Remove the magnet when the desired end position is reached.
Hint:
Whenever changing servo settings, all values should be reprogrammed, i.e.
center and end-limits! Sequence of programming (center, end-limits) does not
really matter.
Attention:
Programmable values for end-limits could possibly be higher than the mechanical
resolution of the servo. The servo therefore could be damaged or function
incorrectly (e.g. wheel spinning) when utilizing the full range. Therefore,
approximate the limiting values carefully. An additionally connected servo tester
(e.g. using the EMCOTEC Mini Servo Tester – part number A71050) can help if
in doubt, indicating the corresponding servo position digitally.
2.4. Deleting all Programming
Total reset of all programmed settings is
possible too. Position the magnet after power
on close to the "PRG" position and hold it
there for approx. 40 seconds. After 2.5
seconds and after additional 5 seconds the servo makes its short move
(just like when programming center/end-limits). The transmitter stick
must not be moved at that time and the magnet must remain at the
"PRG" position. After 40 seconds have elapsed, all settings are deleted
and a restart of the DPSI V-Match takes place. Now, the magnet can
be removed.
Hint:
Whenever programming takes place, the integrated red LED blinks for controlling
purposes at a rate of 0.5Hz (1s on, 1s off) at the DPSI V-Match's side.
