DPSI V-Match Operating Instructions Version 1.0
Page 7 of 16
Hint:
Whenever programming takes place, the integrated red LED blinks for controlling
purposes at a rate of 0.5Hz (1s on, 1s off) at the DPSI V-Match's side.
2.1. Changing Servo Direction
When changing the direction of the servo, all
other settings remain! For reversing direction of
the servo, hold the magnet close to position
"PRG" (red dot on sticker) within the first 10
seconds after power on. Distance of the magnet can be up to 8mm.
The magnet also operates through thin fuselage sidewalls, if the DPSI
V-Match is attached to the fuselage's inner sidewall using e.g. dual
adhesive tape.
2.5 seconds after positioning the magnet, the servo makes a short
move (10% stroke). If the magnet is removed within the next 5
seconds, the servo direction is reversed and permanently stored. The
DPSI V-Match now executes a restart.
