4. Technical Data
Operating Voltage Range 4V .... 8.4V
Current Consumption Approx. 4.7mA
Servo Signal Level Input:
Low-Level 0V ... 0.8V
High-Level 2.0V ... 8.4V
Servo Signal Level Output:
Supplying > 5.1V Approx. 5.0V
Supplying < 5.1V Supply voltage -0,1V
Maximum Allowable Current 8A continuous, 20A peak
Allowable Center Position +/-100% (1.10ms .... 1.90ms)
Allowable End-Limits* +/-200% (0.70ms .... 2.30ms)
Allowable Signal Cycle Time Min. 6.9ms, max. 34.868ms
Resolution (Steps) 3200
CE-Test According to 2004/108/EC
Temperature Range -20°C .... +85°C
HF-Noise Suppression -30dB attenuation @ 35MHz
Dimensions approx. 50mm x 8.4mm x 7.2mm
Weight Approx. 4.5g
Warranty 24 month
* Attention:
Programmable values for end-limits could possibly be higher than the mechanical
resolution of the servo. The servo therefore could be damaged or function
incorrectly (e.g. wheel spinning) when utilizing the full range. Therefore,
approximate the limiting values carefully. An additionally connected servo tester
(e.g. using the EMCOTEC Mini Servo Tester – part number A71050) can help if
in doubt, indicating the corresponding servo position digitally.
Technical modifications and errors excepted!
