DPSI V-Match Operating Instructions Version 1.0
Page 9 of 16
Remove the magnet from its red dot position ("PRG") as soon as the
slave servo reaches the desired center position. The DPSI V-Match
now starts with the newly programmed center position of the slave
servo.
Hint:
Reprogram the end-limits in order to obtain linear curves after programming the
servo center.
2.3. Calibrating End-Limits
Start programming of end-limits just like
programming servo center. Here, the
transmitter stick (or switch actuator) is set to
maximum position (servo end-limit) within 5
seconds after the servo makes its first short move. After these 5
seconds the servo moves again shortly and both servos remain in their
actual (maximum)-position. Reposition the stick to its center position –
servo positions do not alter!
