h) In the Local Area Connection Properties window, select OK.
Note
Connecting to the Gateway's secondary Ethernet port
requires different network settings. Refer to Table 3-1 for
additional network settings.
Table 3-1: Default IP Addresses
Gateway PC/laptop
Ethernet 1 192.168.1.10 192.168.1.12
Ethernet 2 192.168.2.10 192.168.2.12
Ethernet 1 (DeltaV Ready) 10.5.255.254 10.5.255.200
Ethernet 2 (DeltaV Ready) 10.9.255.254 10.9.255.200
Table 3-2: Subnet Settings
Subnet mask
Default 255.255.255.0
DeltaV 255.254.0.0
3. Disable proxies.
a) Open a standard web browser (Internet Explorer, Mozilla
Firefox, or other).
b) Navigate to Tools → Internet Options → Connections →
LAN Settings.
c) Uncheck the box under Proxy Server.
Quick Start Guide September 2020
10 Emerson.com/Rosemount
