10.10 Menu 9: Programmable logic, motorized pot and binary sum
Table 10-15 Menu 9 parameters: single line descriptions
Parameter Range Default Setting Update Rate
9.01 Logic function 1 output OFF(0) or On(1)
21 ms
9.02 Logic function 2 output OFF(0) or On(1)
21 ms
9.03 Motorized pot output ±100.0%
21 ms
9.04 Logic function 1 source 1 Pr 0.00 to Pr 21.51 Pr 0.00
Drive reset
9.05 Logic function 1 source 1 invert OFF(0) or On(1) OFF(0)
21 ms
9.06 Logic function 1 source 2 Pr 0.00 to Pr 21.51 Pr 0.00
Reset
9.07 Logic function 1 source 2 invert OFF(0) or On(1) OFF(0)
21 ms
9.08 Logic function 1 output invert OFF(0) or On(1) OFF(0)
21 ms
9.09 Logic function 1 delay ±25.0 s 0.0
21 ms
9.10 Logic function 1 destination Pr 0.00 to Pr 21.51 Pr 0.00
Drive reset
9.11 Not used
9.12 Not used
9.13 Not used
9.14 Logic function 2 source 1 Pr 0.00 to Pr 21.51 Pr 0.00 Drive reset
9.15 Logic function 2 source 1 invert OFF(0) or On(1) OFF(0)
21 ms
9.16 Logic function 2 source 2 Pr 0.00 to Pr 21.51 Pr 0.00
Drive reset
9.17 Logic function 2 source 2 invert OFF(0) or On(1) OFF(0)
21 ms
9.18 Logic function 2 output invert OFF(0) or On(1) OFF(0)
21 ms
9.19 Logic function 2 delay ±25.0 s 0.0
21 ms
9.20 Logic function 2 destination Pr 0.00 to Pr 21.51 Pr 0.00
Drive reset
9.21 Motorized pot mode 0 to 3 2
BR
9.22 Motorized pot bipolar select OFF(0) or On(1) OFF(0)
21 ms
9.23 Motorized pot rate 0 to 250 s 20
B
9.24 Motorized pot scale factor 0.000 to 4.000 1.000
B
9.25 Motorized pot destination Pr 0.00 to Pr 21.51 Pr 0.00
Drive reset
9.26 Motorized pot up OFF(0) or On(1) OFF(0)
21 ms
9.27 Motorized pot down OFF(0) or On(1) OFF(0)
21 ms
9.28 Motorized pot reset OFF(0) or On(1) OFF(0)
21 ms
9.29 Binary sum one’s input OFF(0) or On(1) OFF(0)
21 ms
9.30 Binary sum two’s input OFF(0) or On(1) OFF(0)
21 ms
9.31 Binary sum four’s input OFF(0) or On(1) OFF(0)
21 ms
9.32 Binary sum output 0 to 255
21 ms
9.33 Binary sum destination Pr 0.00 to Pr 21.51 Pr 0.00
Drive reset
9.34 Binary sum offset 0 to 248 0
21 ms
