Emerson 3403 - Logic Function 2 Source 1;Logic Function 2 Source 1 Invert; Logic Function 2 Source 2; Logic Function 2 Source 2 Invert; Logic Function 2 Output Invert;Logic Function 2 Delay

Introduction
Parameter
x.00
Parameter
description format
Keypad and
display
Serial
communications
CT Modbus
RTU
PLC Ladder
programming
CTSoft Menu 0
Advanced parameter
descriptions
Menu 9
Commander SK Advanced User Guide 123
Issue Number: 9 www.controltechniques.com
This source parameter and Pr 9.04 define the inputs for source 1 of the programmable logic functions.
Any valid parameter can be programmed into these inputs.
If one or both inputs to the logic function are invalid, then the logic output will always be 0.
Setting this parameter and Pr 9.05 to On(1) causes the input sense of the logic functions to be inverted.
This source parameter and Pr 9.06 defines the inputs for source 2 of the programmable logic functions.
Any valid parameter can be programmed into these inputs.
If one or both inputs to the logic function are invalid, then the logic output will always be 0.
Setting this parameter and Pr 9.07 to On(1) causes the input sense of the logic functions to be inverted.
Setting this parameter and Pr 9.08 to On(1) causes the output sense from the logic functions to be inverted.
If the delay parameter is positive, the delay ensures that the output does not become active until an active condition has been present at the input for
9.14 Logic function 2 source 1
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range Pr 0.00 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
9.15 Logic function 2 source 1 invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range OFF(0) or On(1)
Default OFF(0)
Update rate 21 ms
9.16 Logic function 2 source 2
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range Pr 0.00 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
9.17 Logic function 2 source 2 invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range OFF(0) or On(1)
Default OFF(0)
Update rate 21 ms
9.18 Logic function 2 output invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range OFF(0) or On(1)
Default OFF(0)
Update rate 21 ms
9.19 Logic function 2 delay
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range ±25.0 s
Default 0.0
Update rate 21 ms
