Emerson CMF400 - Page 13

12
Figure 9. Power-supply wiring on remote booster amplifier
Drive wires
to the sensor
Remote booster amplifier with core processor
Provide 85-250 VAC power
Remote booster amplifier with junction box
Unused
2
2
N/L2 L/L1
85-250 VAC
N/L2 L/L1
85-250 VAC
1
Drive wires
to the sensor
Provide 85-250 VAC power
1
Remove screw and terminal cover before installing wiring. Re-install cover before operating
Remove screw and terminal cover before installing wiring. Re-install cover before operating
Unused
