Emerson Control Techniques Epsilon Ei - DN Master Receive Bitmap; DN Master Receive FAB Type; DN Master Send Bitmap

27
Configuring the DeviceNet Network
DN Master Receive Bitmap
Ei-DN Modbus Address: 34006
This parameter returns the values for the selected master receive bits.
DN Master Receive FAB Type
Ei-DN Modbus Address: 44005
The DN Master Receive FAB Type displays the chosen fixed assembly block configuration as
shown.
DN Master Send Bitmap
Ei-DN Modbus Address: 34005
This parameter returns the values for the selected master send bits.
Range Units Default Type DN Type Group NVM Res. Access
US16 UINT No RO
Range Units Default Type DN Type Group NVM Res. Access
0-3 ENM Word Yes RW
Value Master Receive FAB Type
0 Index Select (Predef)
1 Index Select (Userdef)
2 Index Type
3 Position Control
Range Units Default Type DN Type Group NVM Res. Access
US16 UINT No RO
