Application Engineering
BULLETIN
AE4-1383 R5
© 2012 Emerson Climate Technologies, Inc.
Printed in the U.S.A.
Heat
Exchanger
Vapor Outlet to
Compressor
Condenser
Outlet
TXV
LIT
VOT
SIT
UT
LOT
Figure 4 – Downstream Extraction
Figure 6 – H/X Piping Arrangement
VO = Vapor temperature leaving H/X
VI = Vapor temperature entering H/X
LI = Liquid temperature entering H/X
LO = Subcooled liquid leaving H/X
Figure 5 – Upstream Extraction
Vapor Out
Cond. Out
Liq. In
TXV
SIT
Liq. Out
Vapor In
Figure 7A
8 - 15 HP Copeland Scroll Compressor
Rack Mounting
102-0283-00
WASHER
027-0115-00
RUBBER PAD
KIT# 998-0178-00
027-0383-00
STEEL SPACER
Figure 7B
8 - 15 HP Condensing Unit
Mounting
028-0188-22
SLEEVE
KIT #527-0210-00
027-0400-00
RUBBER GROMMET
