Emerson Copeland Scroll - R404 A Performance Data

10
Model
Ambient
tem-
perature
(°C)
Evaporating temperature (°C)
-20 -15 -10 -5 0 5
Min Nor Max Min Nor Max Min Nor Max Min Nor Max Min Nor Max Min Nor Max
ZXV065BE
Capacity (kW)
27
1.81 4.66 5.94 2.23 5.46 6.85 2.70 6.47 8.23 3.20 7.49 8.23 3.76 8.32 10.11 4.32 8.78 10.06
32
1.67 4.41 5.68 2.13 5.29 6.62 2.58 6.20 7.87 3.09 7.22 7.87 3.63 8.03 9.75 4.18 8.48 9.74
38
1.57 4.16 5.31 1.93 4.97 6.36 2.41 5.89 7.48 2.98 6.88 7.48 3.48 7.48 9.09 3.99 7.76 8.89
43
1.44 3.88 5.05 1.86 4.77 6.14 2.27 5.55 6.75 2.84 6.53 6.75 3.25 7.04 8.64 3.66 7.25 8.49
Power (kW)
27
0.88 2.16 2.96 0.87 2.31 3.18 0.87 2.35 3.35 0.89 2.55 3.56 0.91 2.70 3.80 0.92 2.91 4.24
32
0.98 2.38 3.24 0.99 2.54 3.44 0.99 2.59 3.64 0.99 2.81 3.95 1.02 3.00 4.28 1.04 3.25 4.85
38
1.13 2.70 3.62 1.13 2.86 3.87 1.13 2.89 4.11 1.14 3.14 4.41 1.18 3.35 4.75 1.22 3.62 5.35
43
1.24 3.03 4.04 1.26 3.19 4.30 1.29 3.24 4.57 1.29 3.50 4.86 1.31 3.66 5.15 1.33 3.91 5.71
ZXV085BE
Capacity (kW)
27
2.29 5.91 7.53 2.83 6.91 8.68 3.42 8.20 10.42 4.05 9.49 10.42 4.76 10.54 12.80 5.47 11.12 12.74
32
2.11 5.59 7.20 2.70 6.70 8.38 3.27 7.85 9.97 3.91 9.15 9.97 4.60 10.17 12.35 5.29 10.74 12.34
38
1.99 5.28 6.73 2.45 6.30 8.06 3.05 7.47 9.47 3.77 8.72 9.47 4.41 9.48 11.52 5.05 9.84 11.26
43
1.83 4.92 6.40 2.35 6.04 7.78 2.88 7.03 8.55 3.60 8.27 8.55 4.12 8.92 10.94 4.64 9.19 10.75
Power (kW)
27
1.12 2.83 3.99 1.10 3.02 4.29 1.10 3.08 4.52 1.13 3.33 4.80 1.15 3.53 5.12 1.17 3.79 5.71
32
1.24 3.11 4.37 1.25 3.32 4.63 1.26 3.39 4.90 1.26 3.68 5.32 1.29 3.92 5.77 1.32 4.24 6.53
38
1.43 3.53 4.88 1.43 3.74 5.22 1.43 3.78 5.54 1.45 4.10 5.94 1.50 4.37 6.40 1.55 4.73 7.20
43
1.57 3.96 5.44 1.60 4.17 5.79 1.64 4.24 6.16 1.64 4.57 6.55 1.66 4.79 6.94 1.68 5.10 7.70
R404A
Note:
• The rating condition is based on a return gas temperature of 18.3°C.
• Power includes condenser fan.
• Ambient 38°C and 43°C are typical design conditions for unit selection.
Performance data
