Quick Installation Guide
P/N MHM-97409.4
April 2010
CSI 9420
10
Table 7. CSI 9420 900 MHz Fast Key Sequence
1420 Wireless Gateway
The wireless network settings can be viewed in the 1420’s web interface. The Network ID
and Join Key needed for theCSI 9420 to join the network can be found on the Setup >
Network > Settings page as illustrated in Figure 7. Select the Yes radio button to display
the Join key.
Once the device has been configured to join the network, navigate to the Explorer page.
This page will show whether the device has joined the network and if it is communicating
properly.
NOTE:
It may take several minutes for the device to join the network.
NOTE:
If the device joins the network and immediately has an alarm present, it is likely due
to sensor configuration. Check the sensor wiring (see figure 3, and tables 1-3) and the
sensor configuration.
Function Key Sequence Menu Items
Device Information 1, 1, 8 Tag, Date, Descriptor, Message, Distributor, Write Protect,
Model, Dev ID, Final assbly num, Revision #’s
Sensor Config 1, 1, 3 Sensor 1, Sensor 2, Calibration
Network 1, 1, 7 Network ID, Set Network ID / Join Key
Variable Mapping 1, 1, 2 PV is, SV is, TV is, QV is
Alarm Levels 1, 1, 6 Overall Velocity Sensor 1, Overall Velocity Sensor 2, PeakVue
Sensor 1, PeakVue Sensor 2, Temperature, Supply Voltage
