28 Digistart IS User Guide
www.controltechniques.com Issue: 4
Model
SCR I
2
t (A
2
s)
Supply Voltage
(< 440 Vac)
Supply Voltage
(< 575 Vac)
Supply Voltage
(< 690 Vac)
IS561410N
6480000
––
––
––
IS561600N
12500000
––
––
––
* Two parallel connected fuses required per phase.
Table 4-4 Ferraz fuses - HSJ
Model
SCR I
2
t (A
2
s)
Supply Voltage
(< 440 Vac)
Supply Voltage
(< 575 Vac)
Supply Voltage
(< 690 Vac)
IS1x0023B
1150
HSJ40**
HSJ40**
IS1x0043B
8000
HSJ80**
HSJ80**
IS1x0053B
15000
HSJ110**
HSJ110**
IS1x0076B
15000
HSJ125**
HSJ125**
IS1x0097B
51200
HSJ175
HSJ175**
IS1x0105B
125000
HSJ225
HSJ225
IS2x0145B
125000
HSJ250
HSJ250**
IS2x0170B
320000
HSJ300
HSJ300
IS2x0200B
320000
HSJ350
HSJ350
IS2x0220B
320000
HSJ400**
HSJ400**
IS3x0255B
320000
HSJ450*
HSJ450**
IS4x0350B
202000
HSJ500**
IS4x0425B
320000
Not suitable
IS4x0500B
320000
IS4x0700B
781000
Not suitable
Not suitable
IS4x0820B
1200000
IS4x0920B
2530000
IS4x1000B
2530000
IS3x0255N
320000
HSJ450**
HSJ450**
IS4x0360N
320000
IS4x0430N
320000
IS4x0650N
1200000
IS4x0790N
2530000
Not suitable
Not suitable
IS4x0930N
4500000
IS561200N
4500000
IS561410N
6480000
IS561600N
12500000
** Two series connected fuses required per phase.
Table 4-5 Ferraz fuses - North American style (PSC 690)
Model
SCR I
2
t (A
2
s)
Supply Voltage
(< 440 Vac)
Supply Voltage
(< 575 Vac)
Supply Voltage
(< 690 Vac)
IS1x0023B
1150
A070URD30XXX0063
A070URD30XXX0063
––
IS1x0043B
8000
A070URD30XXX0125
A070URD30XXX0125
A070URD30XXX0125
IS1x0053B
15000
A070URD30XXX0125
A070URD30XXX0125
A070URD30XXX0125
IS1x0076B
15000
A070URD30XXX0160
A070URD30XXX0160
A070URD30XXX0160
IS1x0097B
51200
A070URD30XXX0200
A070URD30XXX0200
A070URD30XXX0200
IS1x0105B
125000
A070URD30XXX0315
A070URD30XXX0315
A070URD30XXX0315
IS2x0145B
125000
A070URD30XXX0315
A070URD30XXX0315
A070URD30XXX0315
IS2x0170B
320000
A070URD30XXX0315
A070URD30XXX0315
A070URD30XXX0315
IS2x0200B
320000
A070URD30XXX0450
A070URD30XXX0450
A070URD30XXX0450
IS2x0220B
320000
A070URD30XXX0450
A070URD30XXX0450
A070URD30XXX0450
IS3x0255B
320000
A070URD30XXX0450
A070URD30XXX0450
A070URD30XXX0450
IS4x0350B
202000
A070URD31XXX0550
––
––
IS4x0425B
320000
A070URD32XXX0630
––
––
IS4x0500B
320000
A070URD32XXX0700
––
––
IS4x0700B
781000
A070URD33XXX0900
––
––
IS4x1000B
2530000
A070URD33XXX1400
––
––
IS3x0255N
320000
A070URD30XXX0450
A070URD30XXX0450
A070URD30XXX0450
IS4x0360N
320000
A070URD33XXX0630
A070URD33XXX0630
A070URD33XXX0630
IS4x0430N
320000
A070URD33XXX0700
A070URD33XXX0700
––
