Model
SCR I
2
t (A
2
s)
Supply Voltage
(< 440 Vac)
Supply Voltage
(< 575 Vac)
Supply Voltage
(< 690 Vac)
IS4x0650N
1200000
A070URD33XXX1000
A070URD33XXX1000
A070URD33XXX1000
IS4x0790N
2530000
A070URD33XXX1400
A070URD33XXX1400
A070URD33XXX1250
IS4x0930N
4500000
A070URD33XXX1400
A070URD33XXX1400
A070URD33XXX1400
IS561200N
4500000
A055URD33XXX2250
––
––
IS561410N
6480000
A055URD33XXX2250
––
––
IS561600N
12500000
––
––
––
XXX = blade type. See Ferraz catalog for details.
Table 4-6 Ferraz fuses - European style (PSC 690)
Model
SCR I
2
t (A
2
s)
Supply Voltage
(< 440 Vac)
Supply Voltage
(< 575 Vac)
Supply Voltage
(< 690 Vac)
IS1x0023B
1150
6.9URD30XXXX0050
6.9URD30XXXX0050
6.9URD30XXXX0050
IS1x0043B
8000
6.9URD30XXXX0125
6.9URD30XXXX0125
6.9URD30XXXX0125
IS1x0053B
15000
6.9URD30XXXX0125
6.9URD30XXXX0125
6.9URD30XXXX0125
IS1x0076B
15000
6.9URD30XXXX0160
6.9URD30XXXX0160
6.9URD30XXXX0160
IS1x0097B
51200
6.9URD30XXXX0200
6.9URD30XXXX0200
6.9URD30XXXX0200
IS1x0105B
125000
6.9URD30XXXX0315
6.9URD30XXXX0315
6.9URD30XXXX0315
IS2x0145B
125000
6.9URD30XXXX0315
6.9URD30XXXX0315
6.9URD30XXXX0315
IS2x0170B
320000
6.9URD30XXXX0315
6.9URD30XXXX0315
6.9URD30XXXX0315
IS2x0200B
320000
6.9URD31XXXX0450
6.9URD31XXXX0450
6.9URD31XXXX0450
IS2x0220B
320000
6.9URD31XXXX0450
6.9URD31XXXX0450
6.9URD31XXXX0450
IS3x0255B
320000
6.9URD31XXXX0450
6.9URD31XXXX0450
6.9URD31XXXX0450
IS4x0350B
202000
6.9URD31XXXX0550
––
––
IS4x0425B
320000
6.9URD32XXXX0630
––
––
IS4x0500B
320000
6.9URD32XXXX0700
––
––
IS4x0700B
781000
6.9URD33XXXX0900
––
––
IS4x0820B
1200000
6.9URD33XXXX1100
––
––
IS4x0920B
2530000
6.9URD33XXXX1250
––
––
IS4x1000B
2530000
6.9URD33XXXX1400
––
––
IS3x0255N
320000
6.9URD31XXXX0450
6.9URD31XXXX0450
6.9URD31XXXX0450
IS4x0360N
320000
6.9URD33XXXX0630
6.9URD33XXXX0630
6.9URD33XXXX0630
IS4x0430N
320000
6.9URD33XXXX0700
6.9URD33XXXX0700
6.9URD33XXXX0700
IS4x0650N
1200000
6.9URD33XXXX1000
6.9URD33XXXX1000
6.9URD33XXXX1000
IS4x0790N
2530000
6.6URD33XXXX1400
6.6URD33XXXX1400
––
IS4x0930N
4500000
6.6URD33XXXX1400
6.6URD33XXXX1400
––
IS561200N
4500000
6URD233PLAF2200
6URD233PLAF2200
––
IS561410N
6480000
6URD233PLAF2200
6URD233PLAF2200
––
IS561600N
12500000
6URD233PLAF2800
6URD233PLAF2800
––
XXX = blade type. See Ferraz catalog for details.
Table 4-7 Ferraz fuses - AJT
Model
SCR I
2
t (A
2
s)
Supply Voltage
(< 440 Vac)
Supply Voltage
(< 575 Vac)
Supply Voltage
(< 690 Vac)
IS1x0023B
1150
AJT25
AJT25
IS1x0043B
8000
AJT50
AJT50
IS1x0053B
15000
AJT60
AJT60
IS1x0076B
15000
AJT80
AJT80
IS1x0097B
512000
AJT100
AJT100
IS1x0105B
125000
AJT125
AJT125
IS2x0145B
125000
AJT150
AJT150
IS2x0170B
320000
AJT175
AJT175
Not suitable
IS2x0200B
320000
AJT200
AJT200
IS2x0220B
320000
AJT250
AJT250
IS3x0255B
320000
AJT300
AJT300
IS4x0350B
202000
AJT400
AJT400
IS4x0425B
238000
AJT450
AJT450
IS4x0500B
320000
AJT500
AJT500
