Emerson Digistart IS1x0043B series User Manual

Safety
Information
Rating
Data
Mechanical
Installation
Electrical
Installation
Keypad
and
Status
Quick Start
Commissioning
Operation
Programming
Diagnostics
Application
Examples
Technical
Data
Maintenance
Options
Digistart IS User Guide 49
Issue: 4 www.controltechniques.com
Parameter Group
Parameters
Default Value
8 - Analog I/O
M
8A
Analog Input Trip
Do Not Trip
8B
Analog Input Scale
2-10 V
8C
Analog Trip Point
50%
8D
Analog Output A
Current (%FLC)
8E
Analog A Scale
4-20 mA
8F
Analog A Maximum Adjustment
100%
8G
Analog A Minimum Adjustment
0%
8H
Analog Output B
Current (%FLC)
8I
Analog B Scale
4-20 mA
8J
Analog B Maximum Adjustment
100%
8K
Analog B Minimum Adjustment
0%
9 - Display
M
9A
Languages
9B
User Screen - Top Left
Motor Current
9C
User Screen - Top Right
Motor pf
9D
User Screen - Bottom Left
Hours Run
9E
User Screen - Bottom Right
kWh
9F
Graph Data
Current (%FLC)
9G
Graph Timebase
10 seconds
9H
Graph Maximum Adjustment
400%
9I
Graph Minimum Adjustment
0%
9J
F1 Button Action
Setup Auto-Start/Stop
9K
F2 Button Action
None
9L
Current Calibration
100%
9M
Display A or kW
Current
10 - Auto-Reset
M
10A
Auto-Reset Action
Do Not Auto-Reset
10B
Maximum Resets
1
10C
Reset Delay Groups A&B
00:05 (minutes:seconds)
10D
Reset Delay Group C
5 minutes
11 - Secondary Motor Set
M
11A
Motor FLC-2
Model dependent
11B
Dual Thermal Model
Single
11C
Locked Rotor Current-2
600%
11D
Locked Rotor Time-2
00:10 (minutes:seconds)
11E
Motor Service Factor-2
105%
12 - Start/Stop Modes-2
M
12A
Start Mode-2
Constant Current
12B
Current Limit-2
350%
12C
Initial Current-2
350%
12D
Start Ramp-2
00:10 (minutes:seconds)
12E
Adaptive Start Profile-2
Constant Acceleration
12F
Kickstart Level-2
500%
12G
Kickstart Time-2
0 ms
12H
Stop Mode-2
Coast to Stop
12I
Stop Time-2
00:03 (minutes:seconds)
12J
Stop Delay-2
00:00 (minutes:seconds)
12K
Adaptive Stop Profile-2
Constant Deceleration
12L
Adaptive Control Gain-2
75%
12M
Brake Torque-2
20%
12N
Brake Time-2
00:01 (minutes:seconds)
