Emerson Digistart IS1x0043B series User Manual

Safety
Information
Rating
Data
Mechanical
Installation
Electrical
Installation
Keypad
and
Status
Quick Start
Commissioning
Operation
Programming
Diagnostics
Application
Examples
Technical
Data
Maintenance
Options
Digistart IS User Guide 55
Issue: 4 www.controltechniques.com
No
Function
Range
Default
3F
Input B Function
Motor Set Select, Input Trip (N/O), Input Trip
(N/C), Local/Remote Select, Emergency
Run, Emergency Stop, Jog Forward, Jog
Reverse
Input Trip (N/O)
3G
Input B Name
Input Trip, Low Pressure, High Pressure,
Pump Fault, Low Level, High Level, No
Flow, Emergency Stop, Controller, PLC,
Vibration Alarm
Input Trip
3H
Input B Trip
Always Active, Operating Only, Run Only
Always Active
3I
Input B Initial Delay
00:00 to 30:00 (minutes:seconds)
00:00
3J
Input B Trip Delay
00:00 to 04:00 (minutes:seconds)
See Pr 3A to 3E for details of parameter options.
No
Function
Range
Default
3K
Input C Function
Motor Set Select, Local/Remote
Off
3L
Input D Function
Select, Emergency Run, Emergency Stop,
Off
See Pr 3A for details of parameter options.
NOTE
Inputs C and D are only available if the input/output expansion card is installed.
No
Function
Range
Default
3M
Local/Remote
LCL/RMT Anytime, LCL/RMT When Off,
Local Control Only, Remote Control Only
LCL/RMT Anytime
Selects when the LCL/RMT button can be used to switch between local and remote control, and enables or disables the local
control buttons and remote control inputs.
The STOP button on the keypad is always enabled.
LCL/RMT Anytime
LCL/RMT button is always enabled.
LCL/RMT When Off
LCL/RMT button is enabled when the starter is off.
Local Control Only
All remote inputs are disabled.
Remote Control Only
Local control buttons (START, RESET, LCL/RMT) are disabled.
CAUTION
The STOP button on the keypad is always enabled. When using two-wire remote control, the soft starter will restart if
the remote start/stop and reset inputs are still active.
No
Function
Range
Default
3N
Remote Reset Logic
Normally Closed (N/C), Normally Open
(N/O)
Normally Closed
Selects whether the Digistart IS's remote reset input (terminals DI3, +24V) is normally open or normally closed.
No
Function
Range
Default
3O
Comms in Remote
Disable Ctrl in RMT, Enable Ctrl in RMT
Enable Ctrl in RMT
Selects whether the starter will accept Start and Stop commands from the serial communication network when in Remote mode.
The Reset, Force Comms Trip and Local/Remote Control commands are always enabled.
