How to use this guide
This User Guide provides information for operating the drive from start to finish.
The information is in logical order, taking the reader from receiving the drive through to fine tuning the performance.
There are specific safety warnings throughout this guide, located in the relevant sections. In addition, Chapter 1 Safety
Information on page 6 contains general safety information. It is essential that the warnings are observed and the
information considered when working with or designing a system using the drive.
This map of the user guide helps to find the right sections for the task you wish to complete:
3 Mechanical installation
4 Electrical installation
5 Getting started
6 Basic parameters
7 Running the motor
8 Optimization
9 SMARTCARD operation
11 Advanced parameters
12 Technical data
13 Diagnostics
14 UL listing information
