1592001530 XC15-35CX EN r1.2 11.04.2017 XC15-35CX 16/40
o1H
Number of working hours for output oA1 (thousand of)
o1L
Number of working hours for output oA1 (unit of)
o2H
Number of working hours for output oA2 (thousand of)
o2L
Number of working hours for output oA2 (unit of)
dPx
Real probe Px value
dix
Status of digital input “x”
bAu
Baudrate (for communication serial)
r1F
Function linked with Re-start button (immediate)
r2F
Function linked with Re-start button (timed, 3 sec)
S1F
Function linked with Service/Clock button (immediate)
S2F
Function linked with Service/Clock button (timed, 3 sec)
rSt
Restart regulation enabled in case of lockout alarm
rSC
Couter reset enabled
FdY
Firmware release date (day)
FMn
Firmware release date (month)
FYr
Firmware release date (year)
rEL
Firmware release
Ptb
Parameter map progressive number
Example: to calculate the number of activation of oA1 use the following formula:
n1H*1000+n1L.
11. ALARM MENU
The device is able to memorize:
 The total number of alarm events for any managed alarm (max 999)
 Type and duration of last 10 alarm events (ALx, x=0...9)
Moreover, after detecting a new alarm event:
 If a NEW ALARM has been detected, it will be signaled by showing the relative code
on the display and by switching on the ALR icon and blinking the MEM icon
 When at least one alarm is present into memory, the icon MEM will be switched on.
NOTE: after entering the ALARM menu the icon MEM will stop blinking and will stay ON. This is
used to indicate that all alarms in memory have been checked by an operator.
11.1 TYPE OF ALARM EVENTS RECORDER
The following table shows the available information of the alarm menu:
Alarm
Meaning
HA
High pressure/temperature alarm on the suction line
LA
Low pressure/temperature alarm on the suction line
H2
High pressure/temperature alarm on the discharge line
HLL
High pressure lockout alarm
L2
Low pressure/temperature alarm on the discharge line
dLt
High temperature alarm on compressor head
dLL
Lockout due to DLT alarm
ELP
Electronic pressure switch (warning)
ELL
Electronic pressure switch (lockout)
HP
High pressure alarm from external sensor (warning)
LP
Low pressure alarm from external sensor (warning)
HPL
High pressure alarm from external sensor (lockout)
