1592001530 XC15-35CX EN r1.2 11.04.2017 XC15-35CX 20/40
P1E
End of scaling for pressure transducer P1: (P1i to 99.9 bar; P1i to 999 PSI) it is
the pressure value measured from sensor corresponding to 4.5V
P1F
Pressure transducer P1 calibration: depending on the type of sensor as follow
 P1C=0-5  -12.0 to 12.0 bar; -200 to 200 PSI
 P1C=ntC  -12.0 to 12.0°C; -21 to 21°F
P1d
Pressure probe P1 reading error delayed (valid if P1C=0-5): 0 to 255 min
15.3.2 Condensing Probe Configuration
P2P
Condensing probe P2: n=not available (regulation disabled); Y=available
(regulation enabled)
P2C
Condensing transducer configuration:
 0-5= ratiometric transducer (5.0Vdc)
 ntC=temperature probe NTC 10k
P2i
Start of scaling for pressure transducer P2: (-1.5 to P2E bar; -21 to P2E PSI) it
is the pressure value measured from sensor corresponding to 0.5Vdc
P2E
End of scaling for pressure transducer: (P2i to 99.9 bar; P2i to 999 PSI) it is the
pressure value measured from sensor corresponding to 4.5V
P2F
Pressure transducer calibration: depending on the type of sensor as follow
 P2C=0-5  -12.0 to 12.0 bar; -200 to 200 PSI
 P2C=ntC  -12.0 to 12.0°C; -21 to 21°F
P2d
Pressure probe reading error delayed (valid if P2C=0-5): 0 to 255 min
15.3.3 Other Probes Configuration
P3P
Probe P3 presence: n=not available; Y=available
P3C
Probe P3 configuration(*)
 n86=temperature probe NTC86k
 ntC=temperature probe NTC10k
 Pt1=temperature probe PT1000
P3F
Calibration: -12.0 to 12.0°C; -21 to 21°F
P4P
Probe P4 presence: n=not available; Y=available
P4C
Probe P4 configuration(*)
 n86=temperature probe NTC86k
 ntC=temperature probe NTC10k
 Pt1=temperature probe PT1000
P4F
Calibration: -12.0 to 12.0°C; -21 to 21°F
dEr
Delay before activating probe error: 0 to 255 sec
(*)The support of the various types of probes depends on the model.
15.4 DISPLAY
Unt
Unit of measurement for pressure: bar, PSI
CF
Unit of measurement for temperature: °C=Celsius degree; °F=Fahrenheit degree
dLY
Delayed visualization: 0 to 255 sec
Lod
Variable visualization: P1; P2; P3; St1=SETPOINT1 value; St2=SETPOINT2
value; PEr=TRIAC activation in percentage; Aou=analogue output in percentage
15.5 COMPRESSOR CONFIGURATION
CPb
Compressor regulation probe: nP; P1; P2; P3; P4
rtY
Type of regulation: db=dead band; PrP=proportional band
CPo
Compressor power (valid for tandem units): SPo=same power; dPo= different
power
