8 Technical Data
Case 4 DIN
Connectors
Disconnectable terminal block ≤ 2,5 mm2 for valve outputs and minifit
connector for low voltage section
Power Supply 24Vac/dc; Absorption: 40VA max.
Probe Inputs
2 configurable as NTC/PTC/Pt1000
2 configurable as NTC/PTC/Pt1000/4 to 20mA/ to 5V
Valve Output(s) See table on page 3
Serial Connection CanBus and LAN for iCHILL200CX
Data Storing Non volatile memory (EEPROM)
Kind of Action 1B; Pollution Grade: 2; Software Class: A
Rated Impulsive Voltage 2500V; Over-voltage Category: II
Operating Temperature 10 to 60 °C; Storage Temperature: -30 to 85 °C
Relative Humidity 20 to 85% (no condensing)
Measuring and Regulation Range
PTC Probe: -50 to150°C
NTC Probe: -40 to110°C
Pt1000 Probe: -50 to 100°C
Pressure Transducer: -1.0 to 50.0 Bar
Resolution 0,1°C or 1 °F; Precisione@ 25°C: ±0,1 °C ±1 digit
