Chapter 2 Product Introduction 5
EV2000 Series Universal Variable Speed Drive User Manual
Chapter 2 Product Introduction
2.1 Specifications
Table 2-1 General specifications
Item Description
Input
Rated voltage & frequency Three-phase,380V~440V; 50Hz/60Hz
Permissible fluctuation range
Voltage:320V~460V;Voltage unbalance rate:<3%; Frequency:±5%
Output
Rated voltage 380V
Frequency 0Hz~650Hz
Over load ability
Type G: 150% rated current for 1 minute, 200% rated current for 0.5
second;
Type P: 110% rated current for 1 minute, 150% rated current for 1
second
Main control
functions
Modulation mode
Flux vector PWM modulation
Speed range
1:100
Starting torque
180% rated torque at 0.50Hz
Steady accuracy of speed
≤±0.5% rated synchronous speed
Accuracy of frequency
Digital setting: highest frequency×±0.01%;analog setting: highest
frequency×±0.2%
Setting frequency resolution
Digital setting:0.01Hz;analog setting: highest frequency×0.1%
Torque boost
Auto torque boost, Manual torque boost0.1%~30.0%
V/F curve
4 modes: 1 V/F curve mode set by user and 3 kinds of torque-derating
modes (2.0 order, 1.7 order, and 1.2 order)
Acc/Dec curve
3 modes: linear Acc/Dec, S ramp Acc/Dec and auto Acc/Dec; Acc/Dec
time(maximum: 60 hours) and unit(second or minute) are settable.
DC injection braking
Initial frequency of DC injection braking process: 0.20~60.00Hz,
braking time: 0.0～30.0s
braking current: Type G: 0.0～100.0％
Type P: 0.0～80.0％
Jog
Range of jog frequency:0.20Hz~50.00Hz; Acc/Dec time of Jog operation:
0.1~60.0s, Interval of Jog operation is also settable.
Multi-step speed running
Multi-step speed running can be realized by internal PLC or control
terminal
Internal PI Be able to form simple control system easily
Auto-energy saving operation
V/F curve is optimized automatically according to the load condition to
realize energy-saving operation.
Auto voltage regulation(AVR)
When source voltage changes, the modulation rate can be adjusted
automatically, so that the output voltage is unchanged.
Auto current limiting
Operating current is limited automatically to avoid frequent tripping of the
drive.
Auto adjusting of carrier
frequency
Optional function. The carrier frequency can be adjusted automatically
according to the load condition.
