Emerson EV477 - Vcr to Tv Connection

CONNECTIONS (CONTINUED)
After you have connected the antenna to the VCR, you must connect the VCR to the TV.
Find the type of TV you are using and follow the connection diagram.
VCR TO TV CONNECTION
11
NOTE: • A clear picture will not be obtained by the VCR unless the antenna signal is good,
connect the antenna to the VCR properly.
• For the best quality recording, an indoor antenna or a telescopic antenna is not recommended,
the use of an outdoor type antenna is required.
• If you are not sure about the connection, please refer to qualified service personnel.
OR
VHF/UHF IN
UHF
VHF
VHF
UHF
Splitter (Not Supplied) Splitter (Not Supplied)
Cable
From VCR
(RF OUT)
OR
TV
TV TV
