SPECIFICATIONS
SYSTEM VHS
Video signal NTSC color
Channel coverage VHF Channel 2-13
UHF Channel 14-69
CATV Channels A1-A5, A8, A-W, W+1–W+84
VHF output signal Channel 3 or 4 (selectable)
VIDEO
Input: Video line in Phono-type connector 1.0V (p-p)
75 ohms unbalanced, sync. negative
Output: Video line out Phono-type connector 1.0V (p-p)
75 ohms unbalanced, sync. negative
Signal to noise ratio More than 43dB (SP)
Horizontal resolution 220 lines
AUDIO
Input: Audio line in Phono-type connector more than 47K ohms
–8.8 dBm, unbalanced
Output: Audio line out Phono-type connector less than 1.5K ohms
–5.8 dBm (More than 47K ohms load), unbalanced
Frequency response 100Hz-10KHz (SP)
Signal to noise ratio More than 42dB
Audio distortion Less than 4% (SP)
TAPE TRANSPORT
Tape width 12.65mm (1/2")
Tape speed SP: 33.35 mm/sec
EP: 11.12 mm/sec
Maximum recording time 480 min, with T-160 tape (EP)
REW. FF. time Approx 3 min (T-120)
GENERAL
Power requirements AC120V 60Hz only
Power consumption 17W (under 4W in stand-by mode)
DIMENSIONS
Set size (WxHxD) 14.2 x 3.6 x 9.4 inches
Carton size (WxHxD) 17.52 x 6.11 x 12.21 inches
Weight (Net) 6.4 lbs
(Gross) 8.48 lbs
44
