Instruction Manual
D102748X012
DLC3010 Digital Level Controller
Field Communicator Menu Tree
May 2018
108
Figure B‐1. Hot Key
Hot Key
1 Scan Device
2 Write Protect
3 Change Protection
4 PV
5 Change PV
6 Upper Fluid Density
7 Lower Fluid Density
8 Enter Contstant SG
Device Information
1 Identification
2 Revisions
3 Alarm Type and Security
Overview
1 Device Status
2 Comm Status (see 2-2-6 in figure B‐4)
3 Liquid Level
1
3 Interface Level
2
3 Liquid Density
3
4 Process Temperature
5 Analog Output
6 Calibration / Ranging
7 Device Information
1
Alarm Type and Security
1 Alarm Configuration
2 Security
Calibration / Ranging
1 Primary
2 Secondary
3 Ranging
Ranging
1 Upper Sensor Limit
2 Lower Sensor Limit
3 Minimum Span
4 Upper Range Value
5 Lower Range Value
6 Analog Output Action
7 Change Action
8 Level Offset
5
9 Set Level Offset
5
Primary
1 Guided Calibration
2 Full Calibration
3 Partial Calibration
4 Application Notes
Figure B‐2. Overview
Identification
1 Tag
2 Distributor
3 Model
4 Serial Numbers
5 Date
6 Description
7 Message
1‐7-1-4
1-7
Revisions
1 Universal
2 Device
3 Firmware
4 Hardware
5 DD Information
1‐7-3
Alarm Configuration
1 Alarm Jumper
2 Refresh Jumper
3 Signal Levels
Security
1 Write Protect
2 Change Protection
1‐7-3-2
Device Status
1 Refresh Alerts
2 No Active Alerts
4
1‐1
Serial Numbers
1 Device ID
2 Instr Serial Num
3 Sensor Serial Num
4 Final Asmbly Num
Full Calibration
1 Min/Max Calibration
2 Two Point Calibration
3 Weight Calibration
Partial Calibration
1 Capture Zero
2 Trim Gain
3 Trim Zero
Secondary
1 Temperature Calibration
2 Analog Output Calibration
Temperature Calibration
1 Instrument Temperature
2 Instr Tmpr Offset
3 Trim Inst Tmpr
4 Process Temperature
6
5 Proc Tmpr Offset
6
62Trim Proc Tmpr
6
Analog Output Calibration
1 Analog Output
2 Scaled D/A Trim
1-7-1
1-7-2
1‐7-3-1
1-6
1-6-1
1-6-1-2
1-6-1-3
1-6-2
1-6-3
NOTES:
1 APPEARS IN LIQUID LEVEL MODE
2 APPEARS IN INTERFACE LEVEL MODE
3 APPEARS IN LIQUID DENSITY MODE
4 ONLY APPEARS WHEN DEVICE STATUS IS “GOOD”. IF DEVICE STATUS IS NOT GOOD,
5 THERE WILLL BE A MENU FOR EACH ACTIVE ALERT, WHICH WILL EXPAND TO SHOW
5 DESCRIPTIONS, CAUSES, AND RECOMMENDED ACTIONS FOR CLEARING THE ALERT.
5 ABSENT IN LIQUID DENSITY MODE
6 ABSENT WHEN TEMPERATURE SOURCE IS MANUAL ENTRY
Application Notes
1 Calibration Types
2 Calibration Scenarios
Calibration Types
1 Precondition
2 Full Calibration
3 Partial Calibration
1-6-1-4
1-6-1-4-1
Calibration Scenarios
1 Standard Hardware
2 Overweight Displacer
3 Unknown Density
4 Theoretical Calibration
1-6-1-4-2
Standard Hardware
1 Background
2 Precondition
3 Procedure
4 Validation
5 Final Configuration
Theoretical Calibration
1 Background
2 Procedure
3 Final Configuration
Overweight Displacer
1 Background
2 Precondition
3 Procedure
4 Final Configuration
1-6-1-4-2-1
1-6-1-4-2-2
1-6-1-4-2-3
1-6-2-2
1-6-2-1
