Instruction Manual
D103785X012
Field Communicator Menu Trees
June 2017
103
Figure B‐7. Manual Setup > Travel/Pressure Control (2-2-3)
Manual Setup
1 Mode and Protection
2 Instrument
3 Travel/Pressure Control
4 Tuning
5 Valve and Actuator
6 Partial Stroke Test (PST)
7 Outputs
Travel/Pressure Control
HC, AD, PD
1 Travel/Pressure Select
2 Cutoffs and Limits
3 Pressure Control
4 Pressure Fallback
5 Control Mode
6 Characterization
7 Dynamic Response
Pressure Fallback
1 Tvl Dev Press Fallback
2 Tvl Dev Press Fallback Time
3 Fallback Recovery
Pressure Control
1 Pressure Range High
2 Pressure Range Low
Control Mode
1 Control Mode
2 Change Control Mode
3 Restart Control Mode
Characterization
1 Input Characterization
2 Custom Characterization
Dynamic Response
1 SP Rate Open
2 SP Rate Close
3 View/Edit Lag Time
2-2-3-2
Cutoffs and Limits
1 Hi Limit/Cutoff Select
2 Hi Limit/Cutoff Point
3 Lo Limit/Cutoff Select
4 Lo Limit/Cutoff Point
2-2-3-3
2-2-3-7 (AD, PD)
2-2-3-6 (AD, PD)
2-2-3-4 (AD, PD)
2-2-3-5 (AD, PD)
Travel/Pressure Control
ODV
1 Travel/Pressure Select
2 Cutoffs and Limits
3 End Point Pressure Control (EPPC)
4 Pressure Control
5 Pressure Fallback
6 Control Mode
7 Response Control
8 Dynamic Response
HC, AD, PD
Cutoffs and Limits
1 Hi Limit/Cutoff Select
2 Hi Limit/Cutoff Point
3 Lo Limit/Cutoff Select
4 Lo Limit/Cutoff Point
Dynamic Response
1 SP Rate Open
2 SP Rate Close
3 View/Edit Lead/Lag
2-2-3-7
2-2-3-8
ODV
Characterization
1 Input Characterization
2 Custom Characterization
Pressure Fallback
1 Tvl Dev Press Fallback
2 Tvl Dev Press Fallback Time
3 Fallback Recovery
Control Mode
1 Control Mode
2 Change Control Mode
3 Restart Control Mode
2-2-3-6
2-2-3-5
Pressure Control
1 Pressure Range High
2 Pressure Range Lo
2-2-3-4
End Point Pressure Control (EPPC)
1 EPPC Enab
2 Change EPPC Enab
3 EPPC Set Point
4 EPPC Saturation Time
2-2-3
2-2-3
2-2-3-2
2-2-3-3
1 PRESSURE FALLBACK IS AVAILABLE FOR INSTRUMENT LEVEL AD, PD, AND ODV.
1
2-2-3-4 (HC)
2-2-3-6 (HC)
2-2-3-5 (HC)
NOTE:
