Instruction Manual

D103785X012

Field Communicator Menu Trees

June 2017

104

5 PERFORMANCE TUNER IS AVAILABLE FOR INSTRUMENT LEVEL AD, PD, AND ODV.

Figure B‐8. Manual Setup > Tuning (2-2-4) through Manual Setup > Outputs (2-2-7)

Manual Setup

1 Mode and Protection

2 Instrument

3 Travel/Pressure Control

4 Tuning

5 Valve and Actuator

6 Partial Stroke Test (PST)

7 Outputs

Outputs

1 Output Terminal Config

2 Switch Configuration

3 Transmitter Output

4 HART Var Assignments

5 Burst Mode

HART Var Assignments

1 Primary Variable (PV)

2 Secondary Variable (SV)

3 Tertiary Variable (TV)

4 Quaternary Variable (QV)

Output Terminal Config

1 Output Terminal Enable

2 Function

3 Fail Signal

2-2-6 (HD, AD, PD)

2-2-6-1 (HC, AD, PD)

Valve and Actuator

1 Valve Style

2 Actuator Style

3 Feedback Connection

4 Relay Type

5 Zero Power Condition

6 Travel Sensor Motion

7 Maximum Supply Pressure

Pressure Tuning

1 Pressure Tuning Set

2 Proportional Gain

3 MLFB Gain

4 Integral Enable

5 Integral Gain

Travel/Pressure Integral Settings

1 Integral Dead Zone

2 Integrator Limit

Tuning

1 Travel Tuning

2 Pressure Tuning

3 Travel/Pressure Integral Settings

Travel Tuning

1 Travel Tuning Set

2 Proportional Gain

3 Velocity Gain

4 MLFB Gain

5 Integral Enable

6 Integral Gain

7 Performance Tuner

8 Stabilize/Optimize

2-2-5

2-2-4

2-2-6-2 (HC, AD, PD)

2-2-4-3

2-2-4-1

Switch Configuration

1 Limit Switch Trip Point

2 Alert Switch Source

3 Switch Closed

1 PARTIAL STROKE TEST (PST) IS AVAILABLE FOR INSTRUMENT LEVEL ODV.

2 THIS MENU ITEM IS HART VAR ASSIGNMENTS WITH HART 5.

3 THIS MENU ITEM IS TRANSMITTER OUTPUT WITH HART 5.

NOTES:

2-2-7 (ODV)

2-2-4-2

Partial Stroke Test (PST)

1 PST Pressure Limit

2 PST Enable

3 PST Start Point

4 PST Variables

2-2-6

WITH I/O PACKAGE

Burst Mode

1 Burst Enable

2 Burst Command

2-2-7-2 (ODV)

2-2-7-1 (ODV)

WITH I/O PACKAGE

2-2-6-5 (HC, AD, PD)

2-2-7-5 (ODV)

2-2-6-4 (HC, AD, PD)

2-2-7-4 (ODV)

WITHOUT I/O PACKAGE

Outputs

1 HART Var Assignments

2 Burst
