Instruction Manual
D103785X012
Parts
June 2017
91
Figure 7‐3. Typical FIELDVUE DVC6005 HW2 Digital Valve Controller Gauge Configuration
APPLY LUB, SEALANT
SINGLE-ACTING DIRECT SINGLE-ACTING REVERSE
DOUBLE-ACTING
1
NOTE:
1 FOR SINGLE-ACTING DIRECT, OUTPUT B IS PLUGGED.
2 FOR SINGLE-ACTING REVERSE, OUTPUT A IS PLUGGED.
2
49B3261-C SHT 2
