Table 1-4. Hazardous Area Classifications—CSA (Canada)
Certification
Body
Type Certification Obtained Entity Rating Temperature Code
Enclosure
Rating
CSA
DVC60x0
DVC60x0S
(x = 1,2,3)
Ex ia Intrinsically Safe
Class I,II,III Division 1 GP A,B,C,D,E,
F,G per drawing GE42818
Natural Gas Approved
Vmax = 30 VDC
Imax = 226 mA
Ci = 5 nF
Li = 0.55 mH
Pi = 1.4 W
T5(Tamb ≤ 80C)
T6(Tamb ≤ 75C)
Type 4X, IP66
Single Seal Device
Explosion-proof
Class I Division 1 GP B,C,D
Natural Gas Approved
− − −
T5(Tamb ≤ 80C)
T6(Tamb ≤ 75C)
Type 4X, IP66
Single Seal Device
Class I Division 2 GP A,B,C,D
Class II Division 1 GP E,F,G
Class II Division 2 GP F,G
Class III
Natural Gas Approved
− − −
T5(Tamb ≤ 80C)
T6(Tamb ≤ 75C)
Type 4X, IP66
Single Seal Device
DVC6005
Ex ia Intrinsically Safe
Class I,II,III Division 1 GP A,B,C,D,
E,F,G per drawing GE42818
Natural Gas Approved
Vmax = 30 VDC
Imax = 226 mA
Ci = 5 nF
Li = 0.55 mH
Pi = 1.4 W
Voc = 30 VDC
Isc = 12 mA
Ca = 66 nF
La = 246 mH
Po = 86 mW
T5(Tamb ≤ 80C)
T6(Tamb ≤ 75C)
Type 4X, IP66
Single Seal Device
Explosion-proof
Class I Division 1 GP B,C,D
Natural Gas Approved
− − −
T5(Tamb ≤ 80C)
T6(Tamb ≤ 75C)
Type 4X, IP66
Single Seal Device
Class I Division 2 GP A,B,C,D
Class II Division 1 GP E,F,G
Class II Division 2 GP F,G
Class III
Natural Gas Approved
− − −
T5(Tamb ≤ 80C)
T6(Tamb ≤ 75C)
Type 4X, IP66
Single Seal Device
DVC60x5
(x = 1,2,3)
Ex ia Intrinsically Safe
Class I,II,III Division 1 GP A,B,C,D,
E,F,G per drawing GE42818
Vmax = 30 VDC
Imax = 100 mA
Ci = 0 uF
Li = 0 mH
Pmax = 160 mW
T4(Tamb ≤ 125C)
T5(Tamb ≤ 95C)
T6(Tamb ≤ 80C)
Type 4X, IP66
Explosion-proof
Class I Division 1 GP B,C,D
− − −
T4(Tamb ≤ 125C)
T5(Tamb ≤ 95C)
T6(Tamb ≤ 80C)
Type 4X, IP66
Class I Division 2 GP A,B,C,D
Class II Division 1 GP E,F,G
Class II Division 2 GP F,G
Class III
− − −
T4(Tamb ≤ 125C)
T5(Tamb ≤ 95C)
T6(Tamb ≤ 80C)
Type 4X, IP66
