Resource Block (RB) Menu Structure
PARAMETER LABEL MENU STRUCTURE
Alert Key RB > Configure/Setup > Alarm Handling > Alert Key
Block Alarm: Alarm State RB > Device Diagnostics > Block Alarm > Block Alarm: Alarm State
Block Alarm: Unacknowledged RB > Device Diagnostics > Block Alarm > Block Alarm: Unacknowledge
Block Alarm Disabled RB > Configure/Setup > Alarm Handling > Alarm Summary:Disabled.Block Alarm Disabled
Block Alarm Automatically
Acknowledge
RB > Configure/Setup > Alarm Handling > Acknowledge Option.Block Alarm Automatically Acknowledge
Confirm Time RB > Configure/Setup > Alarm Handling > Confirm Time
DD Information RB > Device Variables > DD information
Device ID RB > Configure/Setup > Identification > Device ID or RB > Device Variables > Instrument > Identification > Device ID
Device Revision RB > Configure/Setup > Version > Device Revision or RB > Device Variables > Instrument > Version > Device Revision
Device State
RB > Display > Resource Status > Device State
RB > Device Diagnostics > Device State
Device Type RB > Configure/Setup > Identification > Device Type or RB > Device Variables > Instrument > Identification > Device Type
Diagnostics Options RB > Configure/Setup > Options > Diagnostics Options
Discrete Alarm Disabled RB > Configure/Setup > Alarm Handling > Alarm Summary:Disabled.Discrete Alarm Disabled
Discrete Alarm Automatically
Acknowledge
RB > Configure/Setup > Alarm Handling > Acknowledge Option.Discrete Alarm Automatically Acknowledge
Electronics Serial Number
RB > Configure/Setup > Identification > Elect S/N or RB > Device Variables > Instrument > Identification > Electronics Serial
Number
Factory Serial Number
RB > Configure/Setup > Identification > Factory S/N or RB > Device Variables > Instrument > Identification > Factory Serial
Number
Fault State RB > Device Diagnostics > Maintenance > Fault State
Features Available RB > Configure/Setup > Options > Features Available or RB > Device Variables > Options > Features Available
Features Selected RB > Configure/Setup >Options > Features Selected
Field Serial Number RB > Configure/Setup > Identification > Field S/N or RB > Device Variables > Instrument > Identification > Field Serial Number
Firmware Revision RB > Configure/Setup > Version > Firmware Revision or RB > Device Variables > Instrument > Version > Firmware Revision
Function Block Options RB > Configure/Setup > Options > Function Block Options or RB > Device Variables > Options > Function Block Options
Hardware Revision RB > Configure/Setup > Version > Hardware Revision or RB > Device Variables > Instrument > Version > Hardware Revision
ITK Version RB > Configure/Setup > Version > ITK Version or RB > Device Variables > Instrument > Version > ITK Version
Limit Notify RB > Configure/Setup > Alarm Handling > Limit Notify
Manufacturer RB > Configure/Setup > Identification > Manufacturer or RB > Device Variables > Instrument > Identification > Manufacturer
Maximum Notify RB > Configure/Setup > Alarm Handling > Maximum Notify
Miscellaneous Options RB > Configure/Setup > Options >Miscellaneous Options or RB > Device Variables > Options >Miscellaneous Options
Resource Block Error RB > Device Diagnostics > Resource Block Error
Shed Remote Cascade RB > Configure/Setup > Communication Time Out > Shed Remote Cascade
Shed Remote Out RB > Configure/Setup > Communication Time Out > Shed Remote Out
Standby Firmware Revision
RB > Configure/Setup > Version > Standby Software Revision or RB > Device Variables > Instrument > Version > Standby
Software Revision
Strategy RB > Configure/Setup > Identification > Strategy or RB > Device Variables > Instrument > Identification > Strategy
Tag Description RB > Configure/Setup > Identification > Tag Description or RB > Device Variables > Instrument > Identification > Tag Description
Write Alarm: Alarm State RB > Device Diagnostics > Write Lock > Write Alarm: Alarm State
Write Lock RB > Configure/Setup > Write Lock > Write Lock or RB > Device Diagnostics > Write Lock > Write Lock
Write Priority RB > Configure/Setup > Write Lock > Write Priority
