Emerson Fisher FIELDVUE DVC6000f User Manual

Transducer Block
December 2009
4-59
Table 4-13. Transducer Block Parameter Definitions (Continued)
Label
PARAMETER_NAME
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
INST_ALERTS_CONFIG2
77
Travel Deviation Alert Point
TVL_DEV_ALRT_PT
77.1 RW ALL > 0%, <= 125% 5% SETUP
Data Type: Float
Alerts when difference between sp
and pv is too large for too long.
Travel Deviation Time
TVL_DEV_TIME
77.2 RW ALL > = 0, < = 120 seconds 10 sec SETUP Data Type: Float
Travel Deviation Deadband
TVL_DEV_DB
77.3 RW ALL > = 0%, < = 100% 2% SETUP Data Type: Float
Travel Accumulator Alert Point
TVL_ACCUM_ALRT_PT
77.4 RW ALL > = 0 1,000,000 SETUP
Data Type: Uint32
Alerts when accumulated travel is
too much
Travel Accumulator Deadband
TVL_ACCUM_DB
77.5 RW ALL 0 − 100% 1% SETUP
Data Type: Float
Deadband
Cycle Count Alert Point
CYCLE_COUNT_ALRT_PT
77.6 RW ALL > = 0 1,000,000 SETUP
Alerts when number of cycles is too
large.
Cycle Count Deadband
CYCLE_COUNT_DB
77.7 RW ALL 0 − 100% 1% SETUP
Data Type: Float
Deadband
Travel Open Alert Point
TVL_OPEN_ALRT_PT
77.8 RW ALL −25% to 125% 99.5% SETUP
Data Type: Float
Alert when valve is open. Control
DI channel 24 regardless of alert
enable state.
Travel Open Deadband
TVL_OPEN_DB
77.9 RW ALL > = 0%, < =100% 1% SETUP
Data Type: Float
Deadband
Travel Closed Alert Point
TVL_CLOSED_ALRT_PT
77.10 RW ALL −25% to 125% 0.5% SETUP
Data Type: Float
Alerts when valve closed. Controls
DI channel 25 regardless of alert
enable state.
Travel Closed Deadband
TVL_CLOSED_DB
77.11 RW ALL > = 0%, < = 100% 1% SETUP
Data Type: Float
Deadband
Travel Lo Lo Alert Point
TVL_LO_LO_ALRT_PT
77.12 RW ALL −25% to 125% −25% SETUP
Data Type: Float
Alert when valve position is less
than alert point. Controls DI
channels 26 & 30 regardless of
alert enable state.
Travel Lo Lo Deadband
TVL_LO_LO_DB
77.13 RW ALL > = 0%, < = 100% 5% SETUP
Data Type: Float
Deadband
Travel Lo Alert Point
TVL_LO_ALRT_PT
77.14 RW ALL −25% to 125% −25% SETUP
Data Type: Float
Alert when valve position is less
than alert point. Controls DI
channels 27 & 31 regardless of
alert enable state.
Travel Lo Deadband
TVL_LO_DB
77.15 RW ALL > = 0%, < = 100% 5% SETUP
Data Type: Float
Deadband
Travel Hi Alert Point
TVL_HI_ALRT_PT
77.16 RW ALL −25% to 125% 125% SETUP
Data Type: Float
Alert when valve position is less
than alert point. Controls DI
channels 28 & 32 regardless of
alert enable state.
Travel Hi Deadband
TVL_HI_DB
77.17 RW ALL > = 0%, < = 100% 5% SETUP
Data Type: Float
Deadband
Travel Hi Hi Alert Point
TVL_HI_HI_ALRT_PT
77.18 RW ALL −25% to 125% 125% SETUP
Data Type: Float
Alert when valve position is less
than alert point. Controls DI
channels 29 & 33 regardless of
alert enable state.
Travel Hi Hi Deadband
TVL_HI_HI_DB
77.19 RW ALL > = 0%, < = 100% 5% SETUP
Data Type: Float
Deadband
−Continued−
