DVC6000f Digital Valve Controllers
December 2009
4-66
Table 4-21. Transducer Block, View 4.4
Index Number Parameter
1 ST_REV
76.1 INST_ALERTS_CONFIG.SHUTDOWN_TRIGGER
76.2 INST_ALERTS_CONFIG.SHUTDOWN_RECOVERY
76.3 INST_ALERTS_CONFIG.OUTPUT_BLK_TIMEOUT
76.4 INST_ALERTS_CONFIG.DRIVE_CURRENT_ALRT_PT
76.5 INST_ALERTS_CONFIG.DRIVE_CURRENT_TIME
76.6 INST_ALERTS_CONFIG.TEMP_HI_ALRT_PT
76.7 INST_ALERTS_CONFIG.TEMP_LO_ALRT_PT
76.8 INST_ALERTS_CONFIG.SUP_PRES_HI_ALRT_PT
76.9 INST_ALERTS_CONFIG.SUP_PRES_LO_ALRT_PT
77.1 INST_ALERTS_CONFIG2.TVL_DEV_ALRT_PT
77.2 INST_ALERTS_CONFIG2.TVL_DEV_TIME
77.3 INST_ALERTS_CONFIG2.TVL_DEV_DB
77.4 INST_ALERTS_CONFIG2.TVL_ACCUM_ALRT_PT
77.5 INST_ALERTS_CONFIG2.TVL_ACCUM_DB
77.6 INST_ALERTS_CONFIG2.CYCLE_COUNT_ALRT_PT
77.7 INST_ALERTS_CONFIG2.CYCLE_COUNT_DB
77.8 INST_ALERTS_CONFIG2.TVL_OPEN_ALRT_PT
77.9 INST_ALERTS_CONFIG2.TVL_OPEN_DB
77.10 INST_ALERTS_CONFIG2.TVL_CLOSED_ALRT_PT
77.11 INST_ALERTS_CONFIG2.TVL_CLOSED_DB
77.12 INST_ALERTS_CONFIG2.TVL_LO_LO_ALRT_PT
77.13 INST_ALERTS_CONFIG2.TVL_LO_LO_DB
77.14 INST_ALERTS_CONFIG2.TVL_LO_ALRT_PT
77.15 INST_ALERTS_CONFIG2.TVL_LO_DB
77.16 INST_ALERTS_CONFIG2.TVL_HI_ALRT_PT
77.17 INST_ALERTS_CONFIG2.TVL_HI_DB
77.18 INST_ALERTS_CONFIG2.TVL_HI_HI_ALRT_PT
77.19 INST_ALERTS_CONFIG2.TVL_HI_HI_DB
82 UPGRADE_PROGRESS
87 PROTECTION
Table 4-22. Transducer Block View, 4.5
Index Number Parameter
1 ST_REV
95.1 MAI_CHANNEL_1
95.2 MAI_CHANNEL_2
95.3 MAI_CHANNEL_3
95.4 MAI_CHANNEL_4
95.5 MAI_CHANNEL_5
95.6 MAI_CHANNEL_6
95.7 MAI_CHANNEL_7
95.8 MAI_CHANNEL_8
96 OUTBLOCK_SEL
97 PWA_SET_STATUS
4
