Emerson Fisher FIELDVUE DVC6000f User Manual

ISEL Function Block
December 2009
4-111
Table 4-39. Input Selector Function Block Parameter Definitions (Continued)
Label
PARAMETER_NAME
Description
Initial
Value
Range
Block
Mode
RO /
RW
Index
Number
Update Event
UPDATE_EVT
23
Data Type: DS-73
This alert is generated by any change to the static
data.
UNACKNOWLEDGED 23.1 RW N/A
0=Undefined
1=Acknowledged
2=Unacknowledged
0
UPDATE_STATE 23.2 RO N/A
0=Undefined
1=Update Reported
2=Updated not
reported
0
TIME_STAMP 23.3 RO N/A 0
STATIC_REVISION 23.4 RO N/A 0
RELATIVE_INDEX 23.5 RO N/A 0
Block Alarm
BLOCK_ALM
24
Data Type: DS-72
The block alarm is used for all configuration,
hardware, connection failure, or system problems in
the block. The cause of the alert is entered in the
subcode field. The first alert to become active will set
the active status in BLOCK_ERR. As soon as the
Unreported status is cleared by the alert reporting
task, another block alert may be reported without
clearing the Active status, if the subcode has
changed.
UNACKNOWLEDGED 24.1 RW N/A
0=Undefined
1=Acknowledged
2=
Unacknowledged
0
ALARM_STATE 24.2 RO N/A
0=Undefined
1=Clear reported
2=Clear not reported
3=Active reported
4=Active not
reported
0
TIME_STAMP 24.3 RO N/A 0
SUBCODE 24.4 RO N/A 0
VALUE 24.5 RO N/A 0
Extended Parameters
In 5
IN_5
25 ALL
Status
BAD
NC
constant
Data Type: DS-65
Input value and status.
Value 0
In 6
IN_6
26 ALL
Status
BAD
NC
constant
Data Type: DS-65
Input value and status.
Value 0
In 7
IN_7
27 ALL
Status
BAD
NC
constant
Data Type: DS-65
Input value and status.
Value
In 8
IN_8
28 ALL
Status
BAD
NC
constant
Data Type: DS-65
Input value and status.
Value 0
Disable Analog Input 5
DISABLE_5
29 ALL
Status
BAD
NC
constant
Data Type: DS-66
Enable/Disable for Input_5, If parameter is TRUE
then input is disabled. If parameter status is BAD it is
not evaluated.
Value
0=Use
1=Disable
0
Disable Analog Input 6
DISABLE_6
30 ALL
Status
BAD
NC
constant
0
Data Type: DS-66
Enable/Disable for Input_6, If parameter is TRUE
then input is disabled. If parameter status is BAD it is
not evaluated.
Value
0=Use
1=Disable
0
Disable Analog Input 7
DISABLE_7
31 ALL
Value
BAD
NC
constant
Data Type: DS-66
Enable/Disable for Input_7, If parameter is TRUE
then input is disabled. If parameter status is BAD it is
not evaluated.
Status
0=Use
1=Disable
0
−Continued−
