Emerson Fisher FIELDVUE DVC6000f User Manual

Introduction and Specifications
December 2009
1-11
Table 1-6. Hazardous Area Classifications—IECEx
Certificate Type Certification Obtained Entity Rating
Temperature
Code
Enclosure Rating
IECEx
DVC60x0F
DVC60x0FS
(x = 1,2,3)
Intrinsically Safe
Gas
Ex ia IIC T4/T5/T6
FIELDBUS
T4(Tamb v 80C)
T5(Tamb v 77C)
T6(Tamb v 62C)
IP66
Vmax = 24 VDC
Imax = 380 mA
Ci = 5 nF
Li = 0 mH
Pi = 1.4 W
FISCO
Vmax = 17.5 VDC
Imax = 380 mA
Ci = 5 nF
Li = 0 mH
Pi = 5.32 W
Flameproof
Gas
Ex d IIB+H2 T5/T6
− − −
T5(Tamb v 80C)
T6(Tamb v 75C)
IP66
Type n
Gas
Ex nC IIC T5/T6
− − −
T5(Tamb v 80C)
T6(Tamb v 75C)
IP66
DVC6005F
Intrinsically Safe
Gas
Ex ia IIC T5/T6
FIELDBUS
T5(Tamb v 80C)
T6(Tamb v 75C)
IP66
Vmax = 24 VDC
Imax = 380 mA
Ci = 5 nF
Li = 0 mH
Pi = 1.4 W
Voc = 24 VDC
Isc = 17.5 mA
Ca = 121 nF
La = 100 mH
Po = 105 mH
FISCO
Vmax = 17.5 VDC
Imax = 380 mA
Ci = 5 nF
Li = 0 mH
Pi = 5.32 W
Voc = 24 VDC
Isc = 17.5 mA
Ca = 121 nF
La = 100 mH
Po = 105 mH
Flameproof
Gas
Ex d IIB T5/T6
− − −
T5(Tamb v 80C)
T6(Tamb v 75C)
IP66
Type n
Gas
Ex nC IIC T5/T6
− − −
T5(Tamb v 80C)
T6(Tamb v 75C)
IP66
DVC60x5
(x = 1,2,3)
Intrinsically Safe
Gas
Ex ia IIC T4/T5/T6
Ui = 30 VDC
Ii = 17.5 mA
Ci = 0 uF
Li = 0 mH
Pi = 105 mW
T4(Tamb v 125C)
T5(Tamb v 95C)
T6(Tamb v 80C)
IP66
Flameproof
Gas
Ex d IIC T4/T5/T6
− − −
T4(Tamb v 125C)
T5(Tamb v 95C)
T6(Tamb v 80C)
IP66
Type n
Gas
Ex nA IIC T4/T5/T6
− − −
T4(Tamb v 125C)
T5(Tamb v 95C)
T6(Tamb v 80C)
IP66
1

Emerson Fisher FIELDVUE DVC6000f Specifications

General

Brand	Emerson
Model	Fisher FIELDVUE DVC6000f
Category	Controller
Language	English
