Resource Block
December 2009
4-17
Table 4-3. Resource Block Parameter Definitions (Continued)
Label
PARAMETER_NAME
Description
Initial
Value
RangeMode
RO /
RW
Index
Number
ITK Version
ITK_VER
41 RO N/A *
Data Type: Unsigned16
Major version of ITK test this device has been
tested to. *Initial value depends on the revision
of the DVC6000f.
Extended Parameters
Private Label Distributor
DISTRIBUTOR
42 RO NA 0x5100
Data Type: Unsigned32
Private label distributor
Device String Array
DEV_STRING
43 Unused extended parameter.
Function Block Options
FB_OPTIONS
44 RO
Bits
0: AO
1: DO
2: AI
3: DI
4: PID
5: ISEL
6: OS
7: MAI
All options
enabled
Data Type: Bit String
0=disabled
1=enabled
Indicates which function block licensing options
are enabled. One bit for each block type that is
supported. Unlicensed blocks cannot be
scheduled and the Actual block mode will
remain OOS.
Diagnostic Options
DIAG_OPTIONS
45 RO NA
1=FD Fieldbus
Diagnostics
2=AD Advanced
Diagnostics
3=PD Performance
Diagnostics
*
Data Type: Enum
Indicates which diagnostics licensing options
are enabled. *Initial value depends on the
licensed DVC6000f options.
Miscellaneous Options
MISC_OPTIONS
46 RO NA
0: Software
Download
10: Travel Control
Capable
11: Pressure Control
Capable
12: Fallback Capable
0: 1
10: 1
Data Type: Bit String
0=Disable
1=Enable
Indicates which miscellaneous licensing
options are enabled.
Firmware Revision
FIRMWARE_REVISION
47
Data Type: Uint8
Describes software revision information. This is
the revision of the firmware that is currently in
use.
*Initial value depends on revision of DVC6000f.
FIRMWARE_REV_MAJOR 47.1 RO NA 0−255 *
FIRMWARE_REV_MINOR 47.2 RO NA 0−255 *
FIRMWARE_REV_BUILD 47.3 RO NA 0−255 *
IO_FIRMWARE_REV 47.4 RO NA 0−255 *
DIAG_CAL_REV 47.5 RO NA 0−255 *
FIRMWARE_REV_ALL 47.6 RO NA XX.XX.XX *
Data Type: Visible String
Describes software revision information.
The range of this parameter consists of 47.1
through 47.5 values, converted to text, and
linked together.
*Initial value depends on revision of DVC6000f
Hardware Revision
HARDWARE_REV
48 RO NA
Hardware revision
number
Factory Set
Data Type: Uint8
Describe electronic hardware revision
information.
Electronics Serial Number
ELECTRONICS_SN
49 RO NA NA Factory Set
Data Type: Visible String
Electronics serial number set by
manufacturing.
Factory Serial Number
FACTORY_SN
50 RO NA NA spaces
Data Type: Visible String
Instrument serial number set by manufacturing.
Field Serial Number
FIELD_SN
51 RW NA Any String spaces
Data Type: Visible String
Instrument serial number set in the field.
Detailed Status
DETAILED_STATUS
52 RO NA NA 0
Data Type: Uint32
Not used
Time Since Reset
TIME_SINCE_RESET
53 RO NA NA 0
Number of seconds since the last time
DVC6000f was restarted. Restart due to power
up or restart command.
Device ID
DEVICE ID
54 RO NA NA Device ID
Data Type: Visible String
Unique 32 character ID used to identify the
device.
−Continued−
